S Series

1. S series plastic enclosure's screw thread of the base for connecting cover is molded so that it has sufficient strength and not broken when tightening screw.
2. BOXCO's electrical junction box is designed as 4 side sliding type to be strong against impact.
3. S series enclosure's are suitable for mounting electrical components and available wall mounting. Our plastic enclosures are available in ABS and polycarbonate material.


**Dimensions and specifications are subject to change without notice.

Specification

IP rating
IP 66/67
IK Rating
IK 08
Temperature range
ABS : - 40 ~ + 70℃ | Polycarbonate(PC) : - 40 ~ + 110℃
Flammability Rating
ABS : 94-HB | Polycarbonate(PC) : 94-V-0, 5VA, HB

Model and Size

Size(included cover) Model Mounting Plate Dimension File
W×L×H
(mm)
W×L×H
(inch)
ABS
Grey cover
ABS
Transparent cover
PC
Grey cover
PC
Transparent cover
Steel
1.6mm
Plastic
3~4.5mm
W1 W2 W3 W4 L1 L2 L3 L4 H1 H2 H3 H4 M1
Plate
M2
Plate
DWG 3D PDF
190×190×130 7.48×7.48×5.12 BC-AGS-191913 BC-ATS-191913 BC-CGS-191913 BC-CTS-191913 1919 S 1919 P 190 165 150 120 190 165 90 120 130 114 30 100 159 159 Down Down
190×280×100 7.48×11.02×3.94 BC-AGS-192810 BC-ATS-192810 BC-CGS-192810 BC-CTS-192810 1928 S 1928 P 190 165 150 120 280 255 184 210 100 84 30 70 159 249 Down Down
190×280×130 7.48×11.02×5.12 BC-AGS-192813 BC-ATS-192813 BC-CGS-192813 BC-CTS-192813 1928 S 1928 P 190 165 150 120 280 255 184 210 130 112 30 100 159 249 Down Down
190×280×180 7.48×11.02×7.09 BC-AGS-192818 BC-ATS-192818 BC-CGS-192818 BC-CTS-192818 1928 S 1928 P 190 165 150 120 280 255 184 210 180 162 30 150 159 249 Down Down
190×380×130 7.48×14.96×5.12 BC-AGS-193813 BC-ATS-193813 BC-CGS-193813 BC-CTS-193813 1938 S 1938 P 190 165 150 120 380 355 282 310 130 114 30 100 158 347 Down Down
190×380×180 7.48×14.96×7.09 BC-AGS-193818 BC-ATS-193818 BC-CGS-193818 BC-CTS-193818 1938 S 1938 P 190 165 150 120 380 355 282 310 180 164 30 150 158 347 Down Down
280×280×130 11.02×11.02×5.12 BC-AGS-282813 BC-ATS-282813 BC-CGS-282813 BC-CTS-282813 2828 S 2828 P 280 255 240 210 280 255 182 210 130 114 30 100 248 248 Down Down
280×340×130 11.02×13.39×5.12 BC-AGS-283413 BC-ATS-283413 BC-CGS-283413 BC-CTS-283413 2834S 2834 P 280 255.6 240 210 340 313.8 244 270 130 112 30 100 249 308 Down Down
280×380×130 11.02×14.96×5.12 BC-AGS-283813 BC-ATS-283813 BC-CGS-283813 BC-CTS-283813 2838 S 2838 P 280 254 240 210 380 354 284 310 130 111.4 30 100 249 348 Down Down
280×380×180 11.02×14.96×7.09 BC-AGS-283818 BC-ATS-283818 BC-CGS-283818 BC-CTS-283818 2838 S 2838 P 280 254 240 210 380 354 284 310 180 162 30 150 249 348 Down Down
280×560×130 11.02×22.05×5.12 BC-AGS-285613 BC-ATS-285613 BC-CGS-285613 BC-CTS-285613 2856 S 280 255 240 210 560 535 520 490 130 112 30 100 (251) (531) Down Down
330×430×180 12.99×16.93×7.09 BC-AGS-334318 BC-ATS-334318 BC-CGS-334318 BC-CTS-334318 3343 S 3343 P 330 305 290 260 430 405 334 360 180 160 30 150 294 394 Down Down
380×560×180 14.96×22.05×7.09 BC-AGS-385618 BC-ATS-385618 BC-CGS-385618 BC-CTS-385618 3586 S 380 355 340 310 560 535 520 490 180 160 30 150 (345) (531) Down Down
