ST series : Terminal block box S series, ALS series-for Stair type(BC-ALS-10PT, BC-ALS-15PT incompatible)
FT series : Terminal block box S series, ALS series-for Flat type
AT series : BC-ALS-10PT, BC-ALS-15PT only
Model and Size
| Terminal block Type |
Color |
Number of poles |
Pitch |
File |
| - |
Yellow |
Red |
Blue |
Black |
- |
(mm) |
DWG |
3D |
PDF |
| Stair type/계단형/阶梯形 |
BC-STY-10P |
BC-STR-10P |
BC-STB-10P |
BC-STK-10P |
10P |
8.7 |
Down
|
|
Down
|
| Flat type/일자형/一字形 |
BC-FTY-10P |
BC-FTR-10P |
BC-FTB-10P |
BC-FTK-10P |
10P |
9 |
Down
|
|
Down
|
| Aluminum type/알루미늄용/铸铝形 |
BC-ATY-10P |
BC-ATR-10P |
BC-ATB-10P |
BC-ATK-10P |
10P |
8.2 |
Down
|
|
Down
|
